Table:
D200Z
D200Z design incorporates extreme speeds and precision for tighter tolerances and flawless blends and matches in complex 3-D contoured workpieces.
Table:
148 mm dia Erowa
X:
350 mm
Y:
300 mm
Z:
250 mm
Rapid Traverse:
60 m / min
Pallet:
400 x 400 mm
Table:
500 mm diameter
X:
550 mm
Y:
1000 mm
Z:
500 mm
Rapid Traverse:
X = 48,000 mm/min, Y,Z = 50,000 mm/min
Maximum Workpiece:
Ø650 mm x 420 mm
Table:
300 mm x 340 mm
X:
450 mm
Y:
620 mm
Z:
500 mm
Rapid Traverse:
60,000 mm/min
Maximum Workpiece:
450 mm diameter
Pallet:
400 x 400 mm
Table:
500ø mm
X:
800 mm
Y:
900 mm
Z:
550 mm
Maximum Workpiece:
800ø x 500 mm (conditional)
Table:
800 mm ø
X:
1,200 mm
Y:
1,100 mm
Z:
650 mm
Rapid Traverse:
36,000 mm/min
Maximum Workpiece:
1,000 mm ø x 690.5 mm (with limitations)
Spindle Taper:
#40 / HSK - A63
Pallet:
Optional 1,000 mm x 1,000 mm & 1,250 mm x 1,000 mm
Table:
1,600 mm x 1,200 mm
X:
2,200 mm
Y:
2,300 mm
Z:
1,100 mm
Rapid Traverse:
35,000 (X,Y), 45,000 (Z) mm/min
Maximum Workpiece:
2,100 mm ø x 1,700 mm
Table:
1,300 mm x 1,000 mm
X:
1,300 mm
Y:
1,000 mm
Z:
600 mm
Rapid Traverse:
58 m/min
Maximum Workpiece:
1,500 mm x 1,200 mm x 550 mm
Table:
2,000 mm x 1,300 mm
X:
2,000 mm
Y:
1,300 mm
Z:
800 mm
Rapid Traverse:
58 m/min
Maximum Workpiece:
2,200 mm x 1,500 mm x 700 mm
Table:
2,000 mm x 2,500 mm
X:
2,000 mm
Y:
2,500 mm
Z:
800 mm
Rapid Traverse:
58,000 mm/min (X & Z Axes), 25,000mm/min (Y-Axis)
Maximum Workpiece:
2,000 mm x 2,500 mm x 1,050 mm (with limitation)
